| Artikelnummer: |
NL-BMS-10101 |
The National Luna single battery monitors can be used for any installation that requires careful monitoring of lead-acid battery condition. These monitors use digital technology for increased accuracy and feature low-voltage and over-charge warnings.
The single monitor is available with or without audible alarms. Models with audible alarms have a mute option as well as display on/off option. A brand-new recessed version of the single monitor is available which is flush-mounting and can be used for permanent installations such as caravans, trailers, solar installations and boats.
- Simple installation
- High-accuracy digital technology
- Excessive discharge warning
- Over-charge warning
- Polarity protected
- Extremely low power consumption
- 11.4V to 15V operation (ideal for automotive use)
- Audible alarm option
- Display on/off option (Sleep mode)
- Recessed version available for panel-mounting
| Specifications |
|---|
| Physical size |
94mm (l) x 48mm (w) x 20mm (h) (standard version) |
| Weight |
130g |
| Power supply |
8Vdc - 15Vdc (display range: 11.4V - 14.2V) |
| Low-voltage warning |
DC voltage below 11.4V |
| Over-charge warning |
DC voltage above 14.65V |
| Cable |
3.5 metre moulded ripcord |
| Power consumption |
4mA (sleep mode-option) , 18mA Average |
| 20mA max |
|
